LED lights for railings or handrails
Integrated oblong LED lights for lighting in railings or handrails. The LED lamps are mounted in milled holes.
LED light – Spring
Private and less exposed environment Lighting for railings with round stainless steel handrail and wall handrails. 3 year warranty.
24V, Kelvin 4000, IP 67
Milled holes are required. Mounted with springs. Fully integrated in the same dim 42.4mm as tube. Only suitable for tube size 42.4x2mm
Dimmable. Install with dimmable driver or control with, for example, DALI. Sold individually
Item number: FX100
€68,50 piece incl. VAT
LED light – Hexagon
Public environment Lighting for railings with round stainless steel handrail and wall handrails. 3 year warranty.
24V, Kelvin 4000, IP 67
Milled holes are required. Mounted with hexagon screws. Fully integrated in the same dim 42.4mm as tube. Only suitable for tube size 42.4x2mm
Dimmable. Install with dimmable driver or control with, for example, DALI. Sold individually
Item number: FX100-P
€81,00 piece incl. VAT
Cord 1,0m
CordLED light – 1,0m
Sold individually
Item number: FX150
€6,00 piece incl. VAT
Cord 2,0m
Cord LED light – 2,0m
Sold individually
Item number: FX201
€6,50 piece incl. VAT
Drivder Ferroxled
Driver FerroxLED 24V
For all FerroxLED
Non dimmable, IP67
Item number: FX300
€81,50 piece incl. VAT
Cord 3,6m LED driver
Cord from last LED light to drivder
Only for LED lamp and LED cap Sold individually
Item number: FX225
€19,00 piece incl. VAT
Integrated LED lights in the same radius as the tube 42.4mm. Model with spring for private environments and a model with Allen screws for more public environments.
Neatly integrated and therefore minimally visible. Simple and quick click assembly. Milled holes are required.
Technical data
IP 67
Volt 24DC
Watt 0,48
TA 25grader / TC 35grader
Kelvin 4000
Lumen 28
mA 30
Milled hole,
see drawing
Life span > 50 000 H
Dimmable – yes
Spread angle – 45 degrees
Warrant – 3 years
UV resistant - yes
White
Yes
Parallel connected
LED SMD 2835
IK class:
FX100 – 5
FX100-P – 10
CRI 80
Lightcontrol – yes
Lux height:
900mm – 42
1000mm – 37
1100mm – 31,5
